ZyWALL 10~100 Series Internet Security Gateway
23-2 WAN and Dial Backup Setup
Table 23-1 MAC Address Cloning in WAN Setup
FIELD DESCRIPTION EXAMPLE
MAC Address
Assigned By Press [SPACE BAR] and then [ENTER] to choose one of two methods
to assign a MAC Address. Choose Factory Default to select the factory
assigned default MAC Address. Choose IP address attached on LAN
to use the MAC Address of that workstation whose IP you give in the
following field.
IP address
attached on
LAN
IP Address This field is applicable only if you choose the IP address attached on
LAN method in the Assigned By field. Enter the IP address of the
computer on the LAN whose MAC you are cloning.
192.168.1.35
When you have completed this menu, press [ENTER] at the prompt “Press ENTER to Confirm…” to save
your configuration, or press [ESC] at any time to cancel.
23.3 Dial Backup
The Dial Backup port or CON/AUX port can be used in reserve, as a traditional dial-up connection should
the broadband connection to the WAN port fail. This feature is not available on all models. To set up the
auxiliary port (Dial Backup or CON/AUX) for use in the event that the regular WAN connection is dropped,
first make sure you have set up the switch and port connection (see the Hardware Installation chapter), then
configure
1.
Menu 2 - WAN Setup,
2. Menu 2.1 - Advanced WAN Setup and
3. Menu 11.1 - Remote Node Profile (Backup ISP) as shown next
Refer also to the traffic redirect section for information on an alternate backup WAN connection.
23.4 Configuring Dial Backup in Menu 2
From the main menu, enter 2 to open menu 2.
