ZyWALL 10~100 Series Internet Security Gateway
Log Screens 19-11
19.3.3 Viewing LAN IP Address
In the Reports screen, select LAN IP Address from the Report Type drop-down list box to have the
ZyWALL record and display the LAN IP addresses that the most traffic has been sent to and/or from and
how much traffic has been sent to and/or from those IP addresses.
Computers take turns using dynamically assigned LAN IP addresses. The
ZyWALL continues recording the bytes sent to or from a LAN IP address when it
is assigned to a different computer.
Figure 19-6 LAN IP Address Report Example
The following table describes the fields in this screen.
Table 19-6 LAN IP Address Report
LABEL DESCRIPTION
IP Address This column lists the LAN IP addresses to and/or from which the most traffic has been
sent. The LAN IP addresses are listed in descending order with the LAN IP address to
and/or from which the most traffic was sent listed first.
Amount This column displays how much traffic has gone to and from the listed LAN IP
addresses. The measurement unit shown (bytes, Kbytes, Mbytes or Gbytes) varies
with the amount of traffic sent to and from the LAN IP address. The count starts over
at 0 if the total traffic sent to and from a LAN IP passes the bytes count limit (see
Table 19-7 Report Specifications).
