ZyWALL 10~100 Series Internet Security Gateway
Remote Node Setup 27-7
Figure 27-4 Menu 11.1: Remote Node Profile for PPTP Encapsulation
The next table shows how to configure fields in menu 11.1 not previously discussed.
Table 27-3 Fields in Menu 11.1 (PPTP Encapsulation)
FIELD DESCRIPTION EXAMPLE
Encapsulation Press [SPACE BAR] and then [ENTER] to select PPTP. You must
also go to menu 11.3 to check the IP Address setting once you
have selected the encapsulation method. PPTP
My IP Addr Enter the IP address of the WAN Ethernet port. 10.0.0.140
My IP Mask Enter the subnet mask of the WAN Ethernet port. 255.255.255.0
My Server IP Addr Enter the IP address of the ANT modem. 10.0.0.138
Connection
ID/Name
Enter the connection ID or connection name in the ANT. It must
follow the “c:id” and “n:name” format.
This field is optional and depends on the requirements of your DSL
modem.
N:My ISP
Schedules You can apply up to four schedule sets here. For more details refer
to the Call Schedule Setup chapter.
Menu 11.1 - Remote Node Profile
Rem Node Name= ChangeMe Route= IP
Active= Yes
Encapsulation= PPTP Edit IP= No
Service Type= Standard Telco Option:
Service Name=N/A Allocated Budget(min)= 0
Outgoing= Period(hr)= 0
My Login=
Schedules=
My Password= ******** Nailed-up Connections=
Retype to Confirm= ********
Authen= CHAP/PAP
PPTP : Session Options:
My IP Addr= Edit Filter Sets= No
My IP Mask= Idle Timeout(sec)= 100
Server IP Addr=
Connection ID/Name= Edit Traffic Redirect= No
Press ENTER to Confirm or ESC to Cancel:
Press Space Bar to Toggle.
