ZyWALL 10~100 Series Internet Security Gateway
System Information and Diagnosis 33-3
Table 33-1 System Maintenance: Status Menu Fields
FIELD DESCRIPTION
Status Shows the port speed and duplex setting if you’re using Ethernet Encapsulation
and Down (line is down), idle (line (ppp) idle), dial (starting to trigger a call) and
drop (dropping a call) if you’re using PPPoE Encapsulation.
TxPkts The number of transmitted packets on this port.
RxPkts The number of received packets on this port.
Cols The number of collisions on this port.
Tx B/s Shows the transmission speed in Bytes per second on this port.
Rx B/s Shows the reception speed in Bytes per second on this port.
Up Time Total amount of time the line has been up.
Ethernet Address The Ethernet address of the port listed on the left.
IP Address The IP address of the port listed on the left.
IP Mask The IP mask of the port listed on the left.
DHCP The DHCP setting of the port listed on the left.
System up Time The total time the ZyWALL has been on.
ZyNOS F/W
Version The ZyNOS Firmware version and the date created.
Some ZyWALL models include some or all of the following fields.
Name This is the ZyWALL's system name + domain name assigned in menu 1. For
example, System Name= xxx; Domain Name= baboo.mickey.com
Name= xxx.baboo.mickey.com
Routing Refers to the routing protocol used.
ZyNOS F/W
Version The ZyNOS Firmware version and the date created.
You may enter 1 to drop the WAN connection, 9 to reset the counters or [ESC] to return to menu 24.
33.3 System Information and Console Port Speed
This section describes your system and allows you to choose different console port speeds. To get to the
System Information and Console Port Speed:
