ZyWALL 10~100 Series Internet Security Gateway
29-18 NAT
Figure 29-20 Example 4: Menu 15.1.1.1: Address Mapping Rule
After you’ve configured your rule, you should be able to check the settings in menu 15.1.1 as shown next.
Figure 29-21 Example 4: Menu 15.1.1: Address Mapping Rules
29.5 Trigger Port Forwarding
Some services use a dedicated range of ports on the client side and a dedicated range of ports on the server
side. With regular port forwarding you set a forwarding port in NAT to forward a service (coming in from
Menu 15.1.1.1 Address Mapping Rule
Type= Many-One-to-One
Local IP:
Start= 192.168.1.10
End = 192.168.1.12
Global IP:
Start= 10.132.50.1
End = 10.132.50.3
Press ENTER to Confirm or ESC to Cancel:
Menu 15.1.1 - Address Mapping Rules
Set Name= Example4
Idx Local Start IP Local End IP Global Start IP Global End IP Type
--- --------------- --------------- --------------- --------------- ------
1. 192.168.1.10 192.168.1.12 10.132.50.1 10.132.50.3 M-1-1
2.
3.
4.
5.
6.
7.
8.
9.
10.
Action= Edit Select Rule=
Press ENTER to Confirm or ESC to Cancel:
