ZyWALL 10~100 Series Internet Security Gateway
VPN/IPSec Setup 39-3
Table 39-1 Menu 27.1: IPSec Summary
FIELD DESCRIPTION EXAMPLE
# This is the VPN policy index number. 1
Name This field displays the unique identification name for this VPN rule. The
name may be up to 32 characters long but only 10 characters will be
displayed here. Taiwan
A Y signifies that this VPN rule is active. Y
Local Addr
Start When the Addr Type field in Menu 27.1.1 IPSec Setup is configured to
Single, this is a static IP address on the LAN behind your ZyWALL.
When the Addr Type field in Menu 27.1.1 IPSec Setup is configured to
Range, this is the beginning (static) IP address, in a range of computers
on the LAN behind your ZyWALL.
When the Addr Type field in Menu 27.1.1 IPSec Setup is configured to
SUBNET, this is a static IP address on the LAN behind your ZyWALL.
192.168.1.35
Local Addr
End When the Addr Type field in Menu 27.1.1 IPSec Setup is configured to
Single, this is the same (static) IP address as in the Local Addr Start
field.
When the Addr Type field in Menu 27.1.1 IPSec Setup is configured to
Range, this is the end (static) IP address, in a range of computers on the
LAN behind your ZyWALL.
When the Addr Type field in Menu 27.1.1 IPSec Setup is configured to
SUBNET, this is a subnet mask on the LAN behind your ZyWALL. 192.168.1.38
Encap This field displays Tunnel mode or Transport mode. See earlier for a
discussion of these. You need to finish configuring the VPN policy in menu
27.1.1.1 or 27.1.1.2 if ??? is displayed. Tunnel
