ZyWALL 10~100 Series Internet Security Gateway
27-8 Remote Node Setup
Table 27-3 Fields in Menu 11.1 (PPTP Encapsulation)
FIELD DESCRIPTION EXAMPLE
Nailed-Up
Connections Press [SPACE BAR] and then [ENTER] to select Yes if you want to
make the connection to this remote node a nailed-up connection. No
27.4 Edit IP
Move the cursor to the Edit IP field in menu 11.1, then press [SPACE BAR] to select Yes. Press
[ENTER]
to open Menu 11.3 - Network Layer Options.
Figure 27-5 Menu 11.3: Remote Node Network Layer Options for Ethernet Encapsulation
This menu displays the My WAN Addr field for PPPoE and PPTP encapsulations and Gateway IP
Addr field for Ethernet encapsulation. The following table describes the fields in this screen.
Table 27-4 Remote Node Network Layer Options Menu Fields
FIELD DESCRIPTION EXAMPLE
IP Address
Assignment If your ISP did not assign you an explicit IP address, press [SPACE
BAR] and then [ENTER] to select Dynamic; otherwise select Static
and enter the IP address & subnet mask in the following fields. Dynamic
(default)
(Rem) IP
Address If you have a Static IP Assignment, enter the IP address assigned to
you by your ISP.
Menu 11.3 - Remote Node Network Layer Options
IP Address Assignment= Dynamic
IP Address= N/A
IP Subnet Mask= N/A
Gateway IP Addr= N/A
Network Address Translation= SUA Only
Metric= N/A
Private= N/A
RIP Direction= None
Version= N/A
Multicast= None
Enter here to CONFIRM or ESC to CANCEL:
