ZyWALL 10~100 Series Internet Security Gateway
VPN Screens 15-23
Table 15-9 VPN Manual Setup
LABEL DESCRIPTION
Name Type up to 32 characters to identify this VPN policy. You may use any character,
including spaces, but the ZyWALL drops trailing spaces.
Key Management Select IKE or Manual Key from the drop-down list box. Manual is a useful option for
troubleshooting if you have problems using IKE key management.
Local Local IP addresses must be static and correspond to the remote IPSec router's
configured remote IP addresses.
Two active SAs cannot have the local and remote IP address(es) both the same.
Two active SAs can have the same local or remote IP address, but not both. You can
configure multiple SAs between the same local and remote IP addresses, as long as
only one is active at any time.
Local Address
Type
Use the drop-down list box to choose Single Address, Range Address, or Subnet
Address. Select Single Address for a single IP address. Select Range Address for
a specific range of IP addresses. Select Subnet Address to specify IP addresses on
a network by their subnet mask.
Local IP Address
Start
When the Address Type field is configured to Single Address, enter a (static) IP
address on the LAN behind your ZyWALL. When the Address Type field is
configured to Range Address, enter the beginning (static) IP address, in a range of
computers on the LAN behind your ZyWALL. When the Address Type field is
configured to Subnet Address, this is a (static) IP address on the LAN behind your
ZyWALL.
Local End/Subnet
Mask
When the Address Type field is configured to Single Address, this field is N/A.
When the Address Type field is configured to Range Address, enter the end (static)
IP address, in a range of computers on the LAN behind your ZyWALL. When the
Address Type field is configured to Subnet Address, this is a subnet mask on the
LAN behind your ZyWALL.
Remote Remote IP addresses must be static and correspond to the remote IPSec router's
configured local IP addresses.
Two active SAs cannot have the local and remote IP address(es) both the same.
Two active SAs can have the same local or remote IP address, but not both. You can
configure multiple SAs between the same local and remote IP addresses, as long as
only one is active at any time.
Remote Address
Type
Use the drop-down list box to choose Single Address, Range Address, or Subnet
Address. Select Single Address with a single IP address. Select Range Address
for a specific range of IP addresses. Select Subnet Address to specify IP addresses
on a network by their subnet mask.
Remote IP When the Address Type field is configured to Single Address, enter a (static) IP
