ZyWALL 10~100 Series Internet Security Gateway
29-8 NAT
Table 29-3 Fields in Menu 15.1.1
FIELD DESCRIPTION EXAMPLE
Action The default is Edit. Edit means you want to edit a selected rule (see
following field). Insert Before means to insert a rule before the rule selected.
The rules after the selected rule will then be moved down by one rule. Delete
means to delete the selected rule and then all the rules after the selected one
will be advanced one rule. None disables the Select Rule item. Edit
Select
Rule When you choose Edit, Insert Before or Delete in the previous field the
cursor jumps to this field to allow you to select the rule to apply the action in
question. 1
You must press [ENTER] at the bottom of the screen to save the whole set. You
must do this again if you make any changes to the set – including deleting a rule.
No changes to the set take place until this action is taken.
Selecting Edit in the Action field and then selecting a rule brings up the following menu, Menu 15.1.1.1 -
Address Mapping Rule in which you can edit an individual rule and configure the Type, Local and
Global Start/End IPs.
An IP End address must be numerically greater than its corresponding IP Start
address.
Figure 29-7 Menu 15.1.1.1: Editing/Configuring an Individual Rule in a Set
The following table describes the fields in this screen.
Menu 15.1.1.1 Address Mapping Rule
Type= One-to-One
Local IP:
Start=
End = N/A
Global IP:
Start=
End = N/A
Press ENTER to Confirm or ESC to Cancel:
