ZyWALL 10~100 Series Internet Security Gateway
IP Policy Routing
37-3
Step 2. Type the index of the policy set you want to configure to open Menu 25.1 – IP Routing Policy
Setup.
Menu 25.1 shows the summary of a policy set, including the criteria and the action of a single policy, and
whether a policy is active or not. Each policy contains two lines. The former part is the criteria of the
incoming packet and the latter is the action. Between these two parts, separator “|” means the action is taken
on criteria matched and separator “=” means the action is taken on criteria not matched.
Figure 37-4 Menu 25.1: Sample IP Routing Policy Setup
Table 37-1 IP Routing Policy Setup
ABBREVIATION MEANING
Criterion SA
Source IP Address
SP
Source Port
DA
Destination IP Address
DP
Destination Port
P
IP layer 4 protocol number (TCP=6, UDP=17…)
T
Type of service of incoming packet
PR
Precedence of incoming packet
Action GW Gateway IP address
Menu 25.1 - IP Routing Policy Setup
# A Criteria/Action
- - --------------------------------------------------------------------------
1 Y SA=1.1.1.1-1.1.1.1,DA=2.2.2.2-2.2.2.5
SP=20-25,DP=20-25,P=6,T=NM,PR=0 |GW=192.168.1.1,T=MT,PR=0
2 N __________________________________________________________________________
__________________________________________________________________________
3 N __________________________________________________________________________
__________________________________________________________________________
4 N __________________________________________________________________________
__________________________________________________________________________
5 N __________________________________________________________________________
__________________________________________________________________________
6 N __________________________________________________________________________
__________________________________________________________________________
Enter Policy Rule Number (1-6) to Configure:
