ZyWALL 10~100 Series Internet Security Gateway
18-14 Bandwidth Management Screens
Table 18-3 Bandwidth Manager: Class Setup
LABEL DESCRIPTION
Edit Click Edit to configure the selected class. You cannot edit the root class.
Delete Click Delete to delete the class and all its child-classes. You cannot delete the root
class.
Statistics Click Statistics to display the status of the selected class.
18.9.1 Bandwidth Manager Class Configuration
Configure a bandwidth management class in the Class Configuration screen. You must use the
Bandwidth Manager Summary screen to enable bandwidth management on an interface before you can
configure classes for that interface.
To add a child class, click BW MANAGER, then the Class Setup tab. Click the Add Child-Class button
to open the following screen.
Figure 18-9 Bandwidth Manager: Class Configuration
