ZyWALL 10~100 Series Internet Security Gateway
27-4 Remote Node Setup
Table 27-1 Fields in Menu 11.1
FIELD DESCRIPTION EXAMPLE
My Password Enter the password assigned by your ISP when the ZyWALL calls
this remote node. Valid for PPPoE encapsulation only.
*****
Retype to
Confirm
Type your password again to make sure that you have entered it
correctly. *****
Server IP This field is valid only when RoadRunner is selected in the Service
Type field. The ZyWALL will find the RoadRunner Server IP
automatically if this field is left blank. If it does not, then you must
enter the authentication server IP address here.
Route This field refers to the protocol that will be routed by your ZyWALL –
IP is the only option for the ZyWALL 100. IP
Edit IP This field leads to a “hidden” menu. Press [SPACE BAR] to select
Yes and press [ENTER] to go to Menu 11.3 - Remote Node
Network Layer Options. No
(default)
Session Options
Edit Filter sets
This field leads to another “hidden” menu. Use [SPACE BAR] to
select Yes and press [ENTER] to open menu 11.5 to edit the filter
sets. See the Remote Node Filter section for more details. No
(default)
Once you have configured this menu, press [ENTER] at the message “Press ENTER to Confirm...” to
save your configuration, or press [ESC] at any time to cancel.
27.3.2 PPPoE Encapsulation
The ZyWALL supports PPPoE (Point-to-Point Protocol over Ethernet). You can only use PPPoE
encapsulation when you’re using the ZyWALL with a DSL modem as the WAN device. If you change the
Encapsulation to PPPoE, then you will see the next screen. Please see the Reference Guide for more
information on PPPoE.
