ZyWALL 10~100 Series Internet Security Gateway
VPN/IPSec Setup 39-5
Table 39-1 Menu 27.1: IPSec Summary
FIELD DESCRIPTION EXAMPLE
Remote
Addr End When the Addr Type field in Menu 27.1.1 IPSec Setup is configured to
Single, this is the same (static) IP address as in the Remote Addr Start
field.
When the Addr Type field in Menu 27.1.1 IPSec Setup is configured to
Range, this is the end (static) IP address, in a range of computers on the
network behind the remote IPSec router.
When the Addr Type field in Menu 27.1.1 IPSec Setup is configured to
SUBNET, this is a subnet mask on the network behind the remote IPSec
router.
This field displays N/A when you configure the Secure Gateway Addr
field in SMT 27.1.1 to 0.0.0.0.
172.16.2.46
Secure GW
Addr This is the WAN IP address or the domain name (up to the first 15
characters are displayed) of the IPSec router with which you are making
the VPN connection. This field displays 0.0.0.0 when you configure the
Secure Gateway Addr field in SMT 27.1.1 to 0.0.0.0. 193.81.13.2
Select
Command Press [SPACE BAR] to choose from None, Edit, Delete, Go To Rule,
Next Page or Previous Page and then press [ENTER]. You must select a
rule in the next field when you choose the Edit, Delete or Go To
commands.
Select None and then press [ENTER] to go to the “Press ENTER to
Confirm…” prompt.
Use Edit to create or edit a rule. Use Delete to remove a rule. To edit or
delete a rule, first make sure you are on the correct page. When a VPN
rule is deleted, subsequent rules do not move up in the page list.
Use Go To Rule to view the page where your desired rule is listed.
Select Next Page or Previous Page to view the next or previous page of
rules (respectively).
None
Select Rule Type the VPN rule index number you wish to edit or delete and then press
[ENTER]. 3
When you have completed this menu, press [ENTER] at the prompt “Press ENTER to Confirm…” to save
your configuration, or press [ESC] at any time to cancel.
