Intel386™ EX EMBEDDED MICROPROCESSOR USER’S MANUAL
D-70
D.74 WDTSTATUS
.
WDT Status
WDTSTATUS
(read/write) Expanded Addr:
ISA Addr:
Reset State: F4CAH
—
00H
7 0
WDTEN — — — — — BUSMON CLKDIS
Bit
Number
Bit
Mnemonic
Function
7 WDTEN Watchdog Mode Enabled:
This read-only bit indicates whether watchdog mode is enabled. Only a
lockout sequence can set this bit and only a device reset can clear it.
0 = Watchdog mode disabled
1 = Watchdog mode enabled
6–2 — Reserved. These bits are undefined; for compatibility with future devices,
do not modify these bits.
1 BUSMON Bus Monitor Enable:
0 = Disables bus monitor mode
1 = Enables bus monitor mode
Read this bit to determine the current status. A lockout sequence clears
BUSMON and prevents writes to the WDTSTATUS register.
0 CLKDIS Clock Disable:
Write to this bit to stop or restart the clock to the WDT; read it to
determine the current clock status. A lockout sequence clears CLKDIS
and prevents writing to this register.
0 = Clock enabled
1 = Processor clock (frequency=CLK2/2) disabled (stopped)
