ASYNCHRONOUS SERIAL I/O UNIT
11.3.11 Modem Status Register (MSR n)
Read MSRn to determine the status of the modem control input signals. The upper four bits reflect
the current state of the modem input signals and the lower four bits indicate whether the inputs
(except for RI#) have changed state since the last time this register was read. These lower four
bits are reset to zero when the CPU reads the Modem Status register.
Figure 11-22. Modem Status Register (MSR n )
Modem Status
MSR0, MSR1
(read only)
Expanded Addr:
ISA Addr:
Reset State:
MSR0 MSR1
F4FEH F8FEH
03FEH 02FEH
X0H X0H
7 0
DCD RI DSR CTS DDCD TERI DDSR DCTS
Bit
Number
Bit
Mnemonic
Function
7 DCD Data Carrier Detect:
This bit is the complement of the data carrier detect (DCD n#) input. In
diagnostic test mode, this bit is equivalent to MCR n.3 (OUT2).
6 RI Ring Indicator:
This bit is the complement of the ring indicator (RI n#) input. In diagnostic
test mode, this bit is equivalent to MCR n.2 (OUT1).
5 DSR Data Set Ready:
This bit is the complement of the data set ready (DSR n#) input. In
diagnostic test mode, this bit is equivalent to MCR n.0 (DTR).
4 CTS Clear to Send:
This bit is the complement of the clear to send (CTS n#) input. In
diagnostic test mode, this bit is equivalent to MCR n.1 (RTS).
3 DDCD Delta Data Carrier Detect:
When set, this bit indicates that the DCD n# input has changed state
since the last time this register was read. Reading this register clears
this bit.
2 TERI Trailing Edge Ring Indicator:
When set, this bit indicates that the RI n# input has changed from a low
to a high state since the last time this register was read. Reading this
register clears this bit.
1 DDSR Delta Data Set Ready:
When set, this bit indicates that the DSR n# input has changed state
since the last time this register was read. Reading this register clears
this bit.
0 DCTS Delta Clear to Send:
When set, this bit indicates that the CTS n# input has changed state
since the last time this register was read. Reading this register clears
this bit.
