12.3.11 Channel Mask and Group Mask Registers (DMAMSK and DMAGRPMSK)
Use the DMAMSK and DMAGRPMSK registers to disable (mask) or enable channel hardware
requests. DMAMSK allows you to disable or enable hardware requests for only one channel at a
time, while DMAGRPMSK allows you to disable or enable hardware requests for both channels
at once.
NOTE
Each mask bit is set when its associated channel produces an End-of-Process if
the channel is not programmed for Autoinitialize. Software must then clear the
appropriate mask bit to allow further DREQn requests from initiating
transfers.
Figure 12-29. DMA Channel Mask Register (DMAMSK)
DMA Individual Channel Mask
DMAMSK
(write only) Expanded Addr:
ISA Addr:
Reset State: F00AH
000AH
04H
7 0
— — — — — HRM 0 CS
Bit
Number
Bit
Mnemonic
Function
7–3 — Reserved; for compatibility with future devices, write zeros to these bits.
2 HRM Hardware Request Mask:
0 = Unmasks (enables) hardware requests for the channel specified by
bit 0.
1 = Masks (disables) hardware requests for the channel specified by
bit 0.
NOTE: When this bit is set, the channel can still receive software
requests.
1 0 Must be 0 for correct operation.
0 CS Channel Select:
0 = The selection for bit 2 affects channel 0.
1 = The selection for bit 2 affects channel 1.
