D-1
APPENDIX D
SYSTEM REGISTER QUICK REFERENCE
D.1 PERIPHERAL REGISTER ADDRESSES
Table D-1. Peripheral Register Addresses (Sheet 1 of 6)
Expanded
Address
PC/AT
Address
Access Type
(Byte/Word)
Register Name Reset Value
DMA Controller and Bus Arbiter
F000H 0000H Byte DMA0TAR0/1 (Note 1) XX
F001H 0001H Byte DMA0BYC0/1 (Note 1) XX
F002H 0002H Byte DMA1TAR0/1 (Note 1) XX
F003H 0003H Byte DMA1BYC0/1 (Note 1) XX
F004H 0004H Reserved
F005H 0005H Reserved
F006H 0006H Reserved
F007H 0007H Reserved
F008H 0008H Byte DMACMD1/DMASTS 00H
F009H 0009H Byte DMASRR 00H
F00AH 000AH Byte DMAMSK 04H
F00BH 000BH Byte DMAMOD1 00H
F00CH 000CH Byte DMACLRBP Not a register
F00DH 000DH Byte DMACLR Not a register
F00EH 000EH Byte DMACLRMSK Not a register
F00FH 000FH Byte DMAGRPMSK 03H
F010H Byte DMA0REQ0/1 XX
F011H Byte DMA0REQ2/3 XX
F012H Byte DMA1REQ0/1 XX
F013H Byte DMA1REQ2/3 XX
F014H Reserved
F015H Reserved
F016H Reserved
F017H Reserved
F018H Byte DMABSR X1X10000B
NOTES:
1.
Byte pointer in flip-flop in DMA determines which register is accessed.
2. Shaded rows indicate reserved areas.
