Debugger Components
General Debugger Components
97 Microcontrollers Debugger Manual
Fill Memory
The Fill Memory dialog box shown in Figure 3.39 allows you to fill a memory range
(from Address edit box and to Address edit box) with a bit pattern (value edit box).
Figure 3.39 Fill Memory dialog box
NOTE If Hex Format is checked, numbers and letters are interpreted as hexadecimal
numbers. Otherwise, type expressions and prefix Hex numbers with 0x or $.
Display Address
With the Display Address dialog box, shown in Figure 3.40 , the memory component
dumps memory starting at the specified address.
Figure 3.40 Display Address Dialog Box
NOTE The Show PC dialog box is the same as the Display Address dialog box. In this
dialog box, the Assembly component dumps assembly code starting at the
specified address.
