Freescale Semiconductor Microcontrollers - Manual (Page 465)

HCS08 Full Chip Simulation
Peripheral Modules Commands
465 Microcontrollers Debugger Manual
INPUTS Command
In FCS and CPU-Only Simulation mode, the INPUTS command opens the Simulated Port
Inputs dialog box shown in
Figure 18.39 . The user may then use this box to specify the
input states of port pins and IRQ.
Figure 18.39 Simulated Port Inputs Dialog Box
When using In-Circuit Simulation mode, the INPUTS command shows the simulated
input values to any applicable port.
Syntax
>INPUTS
Example
>INPUTS
Show I/O port input values.
