HC08 FSICEBASE Emulator
Setting Up the System
411
Microcontrollers Debugger Manual
3. Select Communication — The FSICE Communication dialog box opens (
)
4. Specify communication information
a. If you use an ethernet connection to connect your host computer to the
FSICEBASE through a LAN:
• Select TCP/IP, and
• Type the IP address of the FSICEBASE in the text box.
NOTE
The network administrator of your Local Area Network (LAN) needs to assign
the IP address of the FSICEBASE on the network. You can use the default IP
address, and give this address to your network administrator. Or, your network
administrator might choose to create a different IP address. If the network
administrator chooses the IP address, you need to assign the IP address to the
FSICEBASE. For more information see
b. If you use an ethernet connection to connect your host computer directly to the
FSICEBASE (not through a LAN):
• In the Communication dialog box, select TCP/IP, and
• In the text box of the Communication dialog box, type the IP address of the
FSICEBASE
NOTE
Make sure that the cable between the host computer and the FSICEBASE is a
cross-over ethernet cable.
NOTE
Make sure that the host computer uses a static IP address. (The FSICEBASE
does not assign an IP address to the host computer.) If you use the default IP
address of the FSICEBASE (192.168.0.1), we recommend that you assign the
following IP address to the host computer: 192.168.0.2.
NOTE
Make sure that the host computer and FSICEBASE both use the same subnet
mask.
c. If you use a USB cable to connect your host computer directly to the FSICEBASE
station, select USB,
5. Click OK
The debugger attempts to connect to the FSICEBASE. An information box shows the
progress. You can click Cancel in the information box if you do not want to
immediately connect to the FSICEBASE.
