HCS08 Open Source BDM Connection

First Steps From Within an Existing Project

481

Microcontrollers Debugger Manual

Select Derivative Option

Select HCS08 Open Source BDM > Select Derivative to display the

NOTE

If the debugger recognizes only one derivative, this menu entry is not available.

Unsecure Option

Select HCS08 Open Source BDM > Unsecure to unsecure the device when necessary.
This leads to the

dialog box.

Trigger Module Settings

Select HCS08 Open Source BDM > Trigger Module Settings to open the Trigger Module
Settings dialog. For more information see

Bus Trace

Select HCS08 Open Source BDM > Bus Trace to open the Trace component window
within the debugger main window. For more information see

Flash Option

Select HCS08 Open Source BDM > Flash to open the Non-Volatile Memory Control
dialog box. For more information see

Reset to Normal Mode Option

Select HCS08 Open Source BDM > Reset to Normal Mode to reset the hardware CPU to
normal mode.

Show Status Option

Select HCS08 Open Source BDM > Show Status to display the
