HC08 Full Chip Simulation
Configuration Procedure
308 Microcontrollers Debugger Manual
INPUT Command
The INPUT command sets the simulated inputs to port . The CPU reads this input
value when port is set as an input port.
Syntax
INPUT
Where:
is the letter representing corresponding port
Eight-bit simulated value for port
Example
>INPUTA AA
Simulate the input AA on port A.
INPUTS Command
In Full Chip Simulation and CPU-Only Simulation mode, the INPUTS command opens
the Simulated Port Inputs dialog box shown in
Figure 11.54 . Use this box to specify the
input states of port pins and IRQ.
Figure 11.54 Simulated Port Inputs Dialog Box
When using In-Circuit Simulation mode, the INPUTS command shows the simulated
input values to any applicable port.
