Debugger Interface
Debugger Main Window
48
Microcontrollers Debugger Manual
Figure 2.20 Component Menu
describes the Component Menu entries.
NOTE
For a readable display, we recommend using a proportional font (e.g., Courier,
Terminal, etc.).
Select Component > Open to load an extra component window that has not been loaded by
the Debugger at startup. The context-sensitive dialog box presents a set of different
components that are introduced in
.
Select Component > Set Connection and the Set Connection dialog box shown in
is opened.
Table 2.6 Component Menu Description
Menu entry
Description
Open
Loads an extra component window that has not been loaded by
the Debugger at startup. The context-sensitive dialog box
presents a set of different components that are introduced in the
Typical Component Window Display
section.
Set Connection
Sets the Debugger connection.
Fonts
Opens a standard Font Selection dialog box, where you can set
the font used by Debugger components.
Background Color
Opens a standard Color Selection dialog box, where you can
set the background color used by the Debugger component
windows.
