HCS08 Serial Monitor Connection
First Steps from Within an Existing Project
492
Microcontrollers Debugger Manual
MONITOR-HCS08 Menu Options
Once the HCS08 Serial Monitor connection is set, the MONITOR-HCS08 menu entry is
is set in the Debugger menu.
Figure 21.7 MONITOR-HCS08 Menu Entries
Monitor Communication
Select the MONITOR-HCS08 > Monitor Communications option to display the
Setup Window - Monitor Communication Tab
Vector Mirroring Setup
Select the MONITOR-HCS08 > Vector Mirroring Setup option to display the
Setup Window - Vector Table Mirroring Tab
.
Erase Flash
Select the MONITOR-HCS08 > Erase Flash option to immediately erase the target
processor Flash.
Trigger Module Settings
Select the MONITOR-HCS08 > Trigger Module Settings option to open the Trigger
Module Settings dialog box. Refer to the Debugger HCS08 On-chip DBG Module User
Interface manual for all related information.
