Microcontroller Debugging First Steps
Switching Connections
248 Microcontrollers Debugger Manual
3. Press the OK button. The Debugger main menu entry bar for the connection now
changes to HC08FCS.
Figure 10.10 HC08 FCS Menu
You have successfully switched connections to the FCS connection. The values and use of
each HC08FCS menu entry is explained in the Full Chip Simulation chapter of this
manual.
Loading the P&E Multilink/Cyclone Pro
Connection
To load the Multilink/Cyclone Pro connection from within an existing project, take the
following steps:
1. From the Debugger main menu, select Component > Set Connection, as shown below.
Figure 10.11 Component Menu
