ColdFire V1 Full Chip Simulation Connection
584 Microcontrollers Debugger Manual
Memory Block Setting
You must set memory blocks within the available memory; each block must cover a
certain range. The start address and end address define each memory block.
Memory Block Properties
Table 28.3 lists the properties you may specify for a memory block:
Table 28.3 Memory Block Properties
Item Description
Name Name of the memory block.
Type RAM, ROM, Flash, EEPROM or I/O
Start Start address of the memory block
End End address of the memory block
Wait state Time used for reading or writing a specific number of bytes
Bus width Width of the bus that accesses the memory
Read access Table that defines read-access details on Byte, Word, Word
misaligned, Long, and Long misaligned
Write access Table that defines write-access details on Byte, Word, Word
misaligned, Long, and Long misaligned
Auto configure Flag that directs automatic computation of read and write
accesses
Allow misaligned access Flag that allows Word misaligned and Long misaligned
Block type USER_DEF (block you define),
AUTO_GEN (block automatically generated),
AUTO_MEM (master block for standard configuration),
AUTO_RAM (RAM master block for auto configuration), or
AUTO_ROM (ROM master block for auto configuration)
