SofTec RS08 Connection
First Steps From Within an Existing Project
572 Microcontrollers Debugger Manual
MCU Configuration Option
Select SofTec-RS08 > MCU Configuration to display the MCU Configuration dialog box.
About Option
Select the SofTec-RS08 > About option to display the About dialog box.
MCU Configuration Dialog Box
The Hardware Model list menu can be expanded to select another type of BDC debug
interface than the SofTec inDART-RS08. The HW Code list menu can be expanded to
select another RS08 derivative.
Figure 27.6 MCU Configuration Dialog Box
Pressing the Communication Settings button in this window opens the Communication
Settings dialog box.
Communication Settings Dialog Box
The communication dialog box provides chip trimming. The Enable Trimming checkbox
can be checked to enable the trimming data calculation according to the requested DCO
value that can be specified in the DCO Output Frequency (Hz) edit box. The trimming
data is then programmed automatically at application loading time at specified locations
(Flash Trimming locations).
Refer to the inDART®-HCS08 In-Circuit Debugger/Programmer for Motorola HCS08
Family FLASH Devices User’s Manual from SofTec for further details.
