SofTec ColdFire Connection

First Steps From Within an Existing Project

681

Microcontrollers Debugger Manual

SofTec ColdFire Menu Options

Once the SofTec ColdFire connection is set, the connection menu entry in the debugger
main toolbar changes to SofTec-MCF51.

Figure 30.5 SofTec-MCF51 Menu Options

Setup

Select SofTec-MCF51 > Setup to display the

SofTec Coldfire Setup Dialog Box

Communication

Select SofTec-MCF51 > Communication to display the

Target Connection Dialog Box

Select Derivative

Select SofTec-MCF51 > Select Derivative to display the

Set Derivative Dialog Box

Debugging Memory Map

Select SofTec-MCF51 > Debugging Memory Map to display the Debugging Memory Map
dialog. For more information about the Debugging Memory Map menu option, see
Debugging Memory Map window.

Trigger Module Settings

Select SofTec-MCF51 > Trigger Module Settings to open the Trigger Module Settings
dialog. Refer to the Debugger ColdFire On-chip DBG Module User Interface manual for
all related information.
