HC08 FSICEBASE Emulator
Establishing Communication
407 Microcontrollers Debugger Manual
Establishing Communication
The Freescale In-Circuit Emulator Base (FSICEBASE) allows you to connect to a host
computer in two ways:
• Through an ethernet port
• Through a USB port
Communication Through Ethernet Port
If you use an Ethernet connection to establish communication between your host computer
and the FSICEBASE through a LAN, you need to do three things:
• Have network administrator assign IP address on LAN to the FSICEBASE
• Set IP address on FSICEBASE
• Specify IP address in the debugger
The following procedures explains how to do these things step by step.
To establish communication through a LAN:
1. Set up hardware as explained in Setting Up the Hardware .
2. Obtain the IP address that your network administrator assigned to the FSICEBASE
3. Start the debugger as explained in Starting the Debugger .
4. Make sure connection is FSICEBASE
a. From debugger main menu, select Component
b. Select Set Connection — Set Connection dialog box appears
c. Select FSICEBASE emulator from connection drop-down box
d. Click OK — the debugger adds the FSICEBASE-HC08 menu to the main menu
bar
5. From debugger main menu, select FSICEBASE-HC08
6. Select Communication— Communication dialog box appears ( Figure 17.1 )
