HCS08 On-Chip DBG Module
Context Menu Entries in Source, Data, Assembly and Memory Windows
505 Microcontrollers Debugger Manual
Context Menu Entries in Source, Data,
Assembly and Memory Windows
Specific DBG support menu options are added to the Connection menu as soon as the
debugger target processor is acknowledged by the DBG module.
Source and Assembly Windows
Source and Assembly windows have menu entries to set/delete Instruction Triggers A and/
or B, a Trigger Settings to set the DBG module Triggers Settings and the Trigger Module
Usage to set the DBG module functionality globally.
Setting a trigger, which can be assimilated as a complex breakpoint or watchpoint, is as
simple as setting a breakpoint.
Figure 23.2 Source Context Menu - Added Options
Instead of setting a breakpoint, a trigger can be set. Note that only 2 triggers can be set:
Trigger A and Trigger B. In a general way, the on-chip DBG module provides
combinations of trigger A and trigger B conditions, and according to the number of
triggers defined (one or two), different triggers
DBG Module Mode Setup can be chosen.
