SofTec HC08 Connection
From Within an Existing Project
399 Microcontrollers Debugger Manual
About Option
Select the inDART-HC08 > About option to display the About Dialog Box .
MCU Configuration Dialog Box
You can expand the Hardware Model list menu to select another type of debug interface
than the SofTec inDART-HC08. You can expand the Device Code list menu to select
another HC08 derivative.
Figure 16.5 MCU Configuration Dialog Box
Pressing the Communication Settings button opens the Communication Settings Dialog
Box .
Communication Settings Dialog Box
Pressing the Communication Settings button in the MCU Configuration dialog box opens
the Communication Settings dialog box, which allows you to fine-tune critical parameters
needed for proper operation with the chosen target microcontroller.
The dialog box is divided into three sections: Communication Parameters, MON08
Settings and Power Supply Parameters. All of the parameters must be carefully set to
ensure successful operation.
Refer to the inDART®-HC08 In-Circuit Debugger/Programmer for Freescale HC08
Family FLASH Devices User’s Manual from SofTec for further details.
