Sunny Boy Control
SMA Technologie AG
User Manual SUNBC-14:NE0206 84
6.5 Data Archive (DAS Config)
[ DAS CONFIG ]
‡DAS Enable…
……………On On/Off/Permanent
Meas. IntervalŠ
………………15min Timespan for averaging
Max. Storage…
……156.10days Available archiving period (before older data is overwritten)
----------------
„Chan. Select. Selecting measuring channels
Fig. 6.27: Data archive menu “DAS Config”
If “DAS Enable” is set to “Off”, no data will be archived. If set to “On”, system data
will be archived provided communication with the system is possible. If set to “Perma-
nent”, data will be archived continuously, even at night or when no device can be
reached. “Meas. Interval” sets the measuring interval (i.e., the period of time for
which measured values are averaged). The measuring interval can be set between 0
and 240 minutes. If set to 0, the spot values are stored without averaging. The mini-
mum storage time is 5 – 60 seconds, depending on the number of connected de-
vices. “Max. Storage” indicates for how long data can be stored in the memory
before the oldest data will be overwritten. This value depends on the measuring inter-
val, the number of selected channels, and the number of inverters.
Channel Selection
Measuring channels are the data channels that are selected for storage. Any data
channel can be made a measuring channel. The Sunny Boy Control’s default measur-
ing channels for each device are a good selection, suitable for most applications.
However, you can modify the default setting to match your requirements.
