7.5.2 Monitoring Channels (MON-1 – MON-8)
Eight measuring channels of the Sunny Boy Control Plus
can be assigned to the eight
monitoring channels. Each monitoring channel (+Mon1 – +Mon8) can be allocated
different tolerances for generating warning and error messages. If all tolerances are
set to 0, no monitoring will take place. By defining only “Warning Low/High” val-
ues and leaving the “Error Low/High” values on 0, the monitoring channel will
generate warning messages only.
Hardware-Based Configuration
[MONITOR MON-1 ]
Function…
Function of the monitoring channel
…activated
deactivated, activated, daily
---------------Š
Name…
Name of the channel to be monitored (the channel’s default unit
………+PR
for the values below is displayed; here: %)
Warning Low…
………………80%
Warning if channel falls short of this value
Warning High…
………………95%
Warning if channel exceeds this value
Error Low…
………………70%
Error if channel falls short of this value
Error High…
……………100%
Error if channel exceeds this value
Fig. 7.22: Monitoring channel configuration
