SMA Sunny Boy Control User Manual
Page 35
Sunny Boy Control
SMA Technologie AG
User Manual
SUNBC-14:NE0206
31
3.2.2 RS485 Connection Between a PC and a Sunny Boy
Control
PC
Betrieb
Opera
tion
Erdschl
uss
Earth
Fault
Störung
Failur
e
Photovo
ltaik-S
tringw
echsel
richter
Photovo
ltaic st
ring inver
ter
SWR
1100E
Betrie
b
Opera
tion
Erdschl
uss
Earth
Fault
Störung
Failure
volta
ik-Strin
gwec
hselric
hter
voltaic
string
inver
ter
SWR
1100E
Betrieb
Opera
tion
Erdschluss
Earth
Fault
Störung
Failure
Photovolta
ik-Stringwechsel
richter
Photovo
ltaic stri
ng inve
rter
SWR
1100E
Sunny Boy
Control
RS232
PAC 1273
W
max. 50
RS485 / RS232
interface converter
RS485
Fig. 3.13: RS485 connection to a PC
To overcome long distances, for example, it can be useful to connect an RS485 inter-
face to the "PC (COM2)" connector of the Sunny Boy Control. Compared with
RS232, which allows a maximum cable length of approx 15 m / 50 ft, RS485 allows
a total cable length of 1,200 m / 4,000 ft.
To establish an RS485 connection with a PC, you will need an RS485 Piggy-Back
installed to the Sunny Boy Control and an external RS232-RS485 interface converter.
