Sunny Boy Control
SMA Technologie AG
User Manual
SUNBC-14:NE0206
110
Setting Explanation
Fct
Function of the digital input channel
Abbrev. ..... Explanation
-................ deactivated
sw ............ Switch
trlo............ Trigger low, within measuring range Switch on
trhi ............ Trigger high, within measuring range Switch on
impc.......... Continuous impulse counter
impd ......... Daily impulse counter, reset at 00:00 (midnight)
frq ............ Frequency
Name
Name of the channel to be displayed
a) Only for the functions sw, trlo, and trhi:
HighText
Text displayed with the “switched on” condition
LowText
Text displayed with the “switched off” condition
b) Only for the function frq:
Unit
Unit to be displayed
Gain
Conversion from number of impulses to unit of measurement
Offset
Value to be added to the value to be displayed
c) Only for the functions impc and impd:
Unit
Unit to be displayed
Gain
Conversion from number of impulses to unit of measurement
Counter reading
Current count in measuring unit
Table 7.11: Digital input channel configuration
