Sunny Boy Control
SMA Technologie AG
User Manual
SUNBC-14:NE0206
120
Diagnostic Channels
For each activated monitoring channel, a diagnostic channel is automatically gener-
ated. The status of the diagnostic channels can be seen in the menu
"Main Menu…Realtime Data". If the monitoring channel is improperly set up (e.g.,
the channel to be monitored does not exist), the status "Cfg-Error"is displayed.
[SC:REALT. DATA]
:::
‡+Diag MONStart…
Diagnosis of the monitor starting condition “MON-Start”
…OK Š
OK, Cfg-Error, to low, to high, Error Low, Error High
+Diag MON-1…
Diagnosis of the monitoring channel “MON-1”
…Warning Low
OK, Cfg-Error, Warning Low, Warning High, Error Low, Error High
+Diag MON-2…
Diagnosis of the monitoring channel “MON-2”
…OK
OK, Cfg-Error, Warning Low, Warning High, Error Low, Error High
:::
Fig. 7.23: Monitoring channel diagnosis
