Sunny Boy Control
SMA Technologie A
G
User Manual
SUNBC-14:NE0206
57
rable device in the system). “E-Ratio” states the deviation percentage of
“E-Yesterday” compared with “E-Average”.
If “E-Ratio” falls short of the value stated for “Tolerance”, the error message
“Energy” is generated.
State Details
[01:STATE ]
Device ID: status
‡Tolerance…15min
Section 6.2.4
State…
……………Mpp Š
Errors…
……------
Standard display(no error)
occurs for…
This and the following line are displayed only in case of a failure
…………………4min
How long ago the failure occurred
Fig. 5.7: State details from diagnostic report
“Tolerance” refers to the time span set under “Warnings” in
“Setup…System…Tolerances” (refer to section 6.2.4). A warning message will be
generated only if a failure lasts longer than this amount of time.
“State” and “Failures” show the current operating status of the device. If
“Failures” deviates from the setting “-----” (no error), the time passed since the
failure occurred is given below “occurs for”. If “occurs for” exceeds the
“Tolerance” value, the warning message “Device failure” is generated.
Insulation Details
[01:ISOLATION ]
Device ID: isolation
‡Tol.Fail.……500k
Tolerance for generating an error message
Tol.Warn.…1000k
Tolerance for generating a warning message
RIso………………3000k
Current insulation resistance
Fig. 5.21: Insulation details from diagnostic report
“RIso” refers to the current insulation resistance of the device. If the “RIso” value
falls short of the value set for “Tol.Warn.”, a warning message is generated; if it
falls short of the value set for “Tol.Fail.”, an error message is generated.
