102
LINCS Central Control
707024-002
Successful Transmissions
Indicates the number of frames that have been transmitted without excessive collisions,
excessive deferrals, or internal transmission errors.
Transmissions with Collisions
Indicates the number of frames that have been transmitted having one or more collisions.
Deferred Transmissions
Indicates the number of transmissions that have been deferred.
Late Collisions
Indicates the number of transmissions containing illegal collisions.
Excessive Collisions
Indicates the number of transmissions aborted as a result of 16 or more collisions.
Receive Bufs Exhausted
Indicates the number of times that the receive buffers have been exhausted.
Internal Transmission Errors
Indicates the number of transmissions aborted from FIFO Underrun or Byte Count Mismatch.
Successful Receptions
Indicates the number of frames that have been received without CRC or length errors.
Frame Check Sequence Errors
Indicates the number of frames that contained CRC errors that were not alignment errors.
Frame Alignment Errors
Indicates the number of frames with a CRC error that were not correctly aligned on an
8-byte boundary.
Internal Receive Errors
Indicates the number of frames received with lack of adequate buffers, FIFO overruns, or
disabled receivers.
Line Statistics ETH
Line Statistics LINCS C8.2 Central Control
Line: ETH1 Slot: 08 Address: 020011740001
Successful Transmissions 1037528
Transmissions with Collisions 20089
Deferred Transmissions 2074
Late Collisions 0
Excessive Collisions 48
Receive Bufs Exhausted 0
Internal Transmission Errors 48
Successful Receptions 21658053
Frame Check Sequence Errors 34
Frame Alignment Errors 128
Internal Receive Errors 33761
PF: 1-Menu 4-Clr_Ctrs 7-Back 8-Forw 9-Refresh
