Message List
115
9
IEEE 802.11b mode Transmission mode for IEEE 802.11b
(Example: current mode is infrastructure
mode.)
IEEE 802.11b [infrastructure] mode
(Example: current mode is 802.11 ad hoc
mode.)
IEEE 802.11b [802.11 ad hoc] mode
(Example: current mode is ad hoc mode.)
IEEE 802.11b [ad hoc] mode
IEEE 802.11b current channel The current channel is displayed.
The value selected by the user is displayed in
ad hoc mode.
The channel used in the access point is dis-
played in infrastructure mode.
(Example: current channel is 11.)
IEEE 802.11b current channel 11
IEEE 802.11b Card Firmware REV. IEEE 802.11b interface unit Firmware version
(Example: current version is 0.8.3.)
IEEE 802.11b interface unit Firmware REV.
0.8.3
IEEE 802.11b MAC Address = dress> The IEEE 802.11b I/F MAC address is dis-
played.
(Example: current MAC address is
00:00:74:XX:XX:XX.)
IEEE 802.11b MAC Address =
00:00:74:XX:XX:XX
IEEE 802.11b SSID (AP MAC Address <
MAC Address>) The access point SSID used in infrastructure
mode and the MAC address of the access
point are displayed.
(Example: current MAC address is
xx:xx:xx:xx:xx:xx and SSID value is “test-
ssid”.)
IEEE 802.11b SSID test-ssid (AP MAC Ad-
dress xx:xx:xx:xx:xx:xx)
IEEE 802.11b TX Rate The IEEE 802.11b transmitting speed (set
speed) is displayed.
(Example: current Tx Rate is 11 Mbps.)
IEEE 802.11b Tx Rate 11 Mbps
Transmission speeds vary depending on sig-
nal quality. Displayed values may differ from
actual transmission speed.
inetd start. An inetd has started.
started with IP: has been set for and
started.
Message Causes and solutions
