Fuel Point PLUS Vehicle Installation and Configuration Manual 123
Post Programming Malfunctions
1.
DataPass parameters
cannot be modified
1. Check Fuel Ring by placing WP coil next to tested coil.
2. Access WP Functions → Read String:
If vehicle parameters appear (e.g. vehicle number, fuel
type, etc.), ID chip is good.
If No VIU detected message appears, coils are too far
from each other, ID chip is not good, or disconnected
(check wiring).
3. To check DataPass reading and its parameters via MAC
address:
a. Using the arrow keys scroll down to access the
Tech functions
menu
b. Select Tech functions→ DataPass parameters
→Use Mac Address. DP Address: screen
appears
c. Enter 8 last digits of DataPass/µDataPass MAC
address: if the parameters are displayed
DataPass/µDataPass is OK
d. If the DP Read Error message appears,
probably DataPass/µDataPass is not assembled
properly, or is defective, or bad wiring.
Check wiring, or replace DataPass/µDataPass
4. Check DataPass versus ID chip:
a. Place WP coil above Fuel Tank coil
b. Access WP Functions → DP Parameters. If
parameters are displayed, DataPass/µDataPass
is OK
c. If the No VIU Detected message appears,
probably DataPass/µDataPass is not assembled
properly, coils are too far from each other, or
ID chip is not identified by programmer
(disconnected or broken)
5. If MAC address cannot be found:
a. Access WP Functions → Check DP
b. Enter vehicle number, press ENTER and then
SEND. The SEND To message appears: press
SEND again. If DataPass/µDataPass is
connected and operational, the MAC address is
