Leica Geosystems Leica mojo3D - User Manual - Manual (Page 361)

Leica mojo3D, mojo3D Enhancements 361
14. Wait until the further tuning of the inertial sensors is complete, as shown by the
progress bar, and then tap to continue.
15. Enter the Orientation of the
mojoXact by tapping the or
until the correct orientation is
displayed. The mojoXact will rotate
to help with entering the correct
value.
16. When completed, tap to continue.
17. Select the steer kit attached to the mojoXact by tapping the steer kit name in
the list. Tap or to reveal more options in the list.
18. Tap to continue.
Depending on the steer kit selected, The Select the model and make screen or
the Steering Kit Status screen appears.
19. If the Select the model and make screen appears, select the model and make
appropriate for your steer kit by tapping on their names in the list. Tap to
continue and the Steering Kit Status screen appears.
