Leica mojo3D, mojo3D Enhancements 347

If Direct Section Control has been unlocked, other Section Controllers will
appear in the list.
47. Tap to select implement mode:
• Sprayer Mode: is used for most situations, this allows the section control to
be optimally setup for general applications.
• Planter Mode: optimises the system for operating a planter and if selected,
reverses the polarity of the Leica AS400 normal operation.
48. Tap to continue.
The master input source screen appears.
49. On the master input source screen, in the list at the left of the screen, tap to
select the master input source.
50. In the list at the right of the screen, tap to select the input mode.

The Master Input Source & Input Mode options available will depend on the
configuration of the individual system:
• mojo3D / Touch: the on screen coverage mapping is activated by touching the
Master Record button on the screen.
• mojo3D / Master Input: the on screen coverage mapping is activated by
sensing a voltage connected to the Master wire on the mojo3D power cable.
