112 Leica mojo3D, Auto-Steer
5.2.5 Speed Adjust
Setting the speed
adjust The speed adjust should be used to fine tune the performance of the control system
for higher speeds than the tuning speed of 5 km/h (3 mph). Typically, the vehicle can
steer side to side at higher speeds, and this can be resolved by reducing the speed
adjust. If the vehicle does not hold the line well at the desired speed, then increase
the speed adjust.
2. Adjust the slider to vary the speed adjust, by using the left and right arrows.

• The speed adjust can be set between 50% and 150%. The standard value is
100%.
• The speed adjust has no effect at or below 5 km/h (3 mph).
1. On the tuning screen, tap the speed adjust button.
