Leica mojo3D, mojo3D Enhancements 317
5. Tap to select implement mode:
• Sprayer Mode: is used for most situations, this allows the section control to
be optimally setup for general applications.
• Planter Mode: optimises the system for operating a planter and if selected,
reverses the polarity of the Leica AS400 normal operation.
6. Tap to continue.
7. Tap to select the master input source, and input mode:

The Master Input Source & Input Mode selection will depend on the config-
uration of the individual system:
• mojo3D / Touch: the on screen coverage mapping is activated by touching a
button on the screen.
• mojo3D / Master Input: the on screen coverage mapping is activated by
sensing a voltage connected to the Master wire on the mojo3D power cable.
• Leica AS400 / Single: the on screen coverage mapping is activated by sensing
a voltage connected to the Master wire on the Leica AS400 controller port. This
is only available with specific rate controller cables.
• Leica AS400 / Dipole Switch: the on screen coverage mapping is activated
by sensing a pair of switching wires. This is only available with specific rate
controller cables.
8. Tap , the section control setup screen is shown.
