Leica Geosystems Leica mojo3D - User Manual - Manual (Page 358)

358 Leica mojo3D, mojo3D Enhancements
4. Select the necessary correction
type from the list.

This will depend on the particular installation and the method chosen for
GPS corrections, for example Base Station via internal radio.
5. Additional configuration information will need to be selected for most Correction
Source options. After setting this information tap to continue.
6. The screen will display the correction data being received and also the strength
of the correction signal. Tap to continue.

If GL1DE
TM
Only was selected this screen will not be displayed.
7. If a correction source other than GL1DE
TM
Only was selected, the Enable GL1DE
Fallback screen appears. At this screen the operator can choose to have the
system use the GL1DE
TM
correction source in the event that their chosen correc-
tion source fails. To select this option, tap the Enable GL1DE
TM
Fallback box so it
turns green.
