Leica mojo3D, System Overview 15
1.3 Features and Specifications
1.3.1 mojo3D Hardware
mojo3D hardware
features
• Simple installation, with RAM mount and colour-coded quick-install antennas
• Integrated L1 GPS receiver
• Integrated cell modem, CDMA or HSDPA depending on region ordered
• 12 volt operation
• Internal storage for waylines, worked areas, and settings
a) USB interface for data transfer
b) Power button
c)
7" colour touch screen
d) Port expansion connector
e) Connector for GPS antenna, blue
f)
Connector for cell modem antenna,
purple
g) Power connector
h) Cover for SIM card slot
i)
RAM mount - ball
a c b
g
d e f
h i
mojo3D_002
