230 Leica mojo3D, NMEA Output
11.2 Logging NMEA Data to USB
General informa-
tion The NMEA output can be logged to a USB Flash Drive for post-processing of the data.

• Refer to "11 NMEA Output" for more information about NMEA.
• Refer to "Appendix B Formatting USB Flash Drives" for important information
about using USB drives with the mojo3D products.
Logging NMEA data
to USB, step-by-
step To enable logging of NMEA data to USB, carry out the following steps:
1. The USB interface is on the lower left front of the
mojo3D display. Lift the rubber cover and insert a
compatible USB Flash Drive into the USB slot.
2. On the main navigation screen, tap the settings button.
mojo3D_010
