346 Leica mojo3D, mojo3D Enhancements
• Use the on-screen keyboard to enter data, tap to continue.
• Repeat for all measurements required.
43. If more implements are required, tap to add another implement. To change
settings for the vehicle or implements already set up, tap the relevant button in
the top bar.
44. After you have entered all the required settings, tap to continue.
The Minimum Turn Radius screen appears.
45. On the Minimum Turn Radius screen enter an appropriate value for your setup,
and tap to continue.
The section controller/implement mode setup screen appears.
46. On the section controller/implement mode setup screen, in the list at the left of
the screen, tap to select section controller type:
• None: section control is disabled.
• On Screen: sections are shown on screen turning on & off, but no physical
control of sections is possible.
• Single Section: a maximum of one section can be setup for the vehicle. This
section is automatically controlled with physical output on the port expansion
cable.
• Leica AS400: multiple sections are automatically controlled via the Leica
AS400 section controller hardware, supplied with the multi-section control kit.
