348 Leica mojo3D, mojo3D Enhancements
• Leica AS400 / Single: the on screen coverage mapping is activated by sensing
a voltage connected to the Master wire on the Leica AS400 controller port.
This is only available with specific rate controller cables.
• Leica AS400 / Dipole Switch: the on screen coverage mapping is activated
by sensing a pair of switching wires. This is only available with specific rate
controller cables.
51. Tap to continue.
The section control setup screen appears.
52. The section control setup screen initially shows one section, as a single blue bar
near the top of the screen. To set the number of sections, tap the number of
sections field, enter the number of sections, and tap .
53. The blue bar will be divided showing the number of sections set. To set the width
of the first section, tap the section width field, enter the width measurement
and tap .
54. Tap at the top right corner of the screen, the selected section in the bar will
be coloured blue. Set the width of the section the same way by tapping on the
section width field.
