Leica mojo3D, mojo3D Enhancements 359
• GL1DE
TM
Fallback Time Limit is the time in minutes that the system will use the
GL1DE
TM
correction source. If the originally configured correction source has
not come back online in this time period, then auto-steer is disabled.
• Drift Limit - if the originally configured correction source comes back online
and the drift from the wayline is less than this value (in metres) then auto-
steer remains enabled. However, if the drift from the wayline is greater than
this value, then auto-steer is disabled.
Select or deselect Enable GL1DE
TM
Fallback and tap the button. The Antenna
Separation/Vehible Height/Red Antenna Offset screen appears.
8. Measure the distance shown by the
image, then tap the measurement
value field under the relevant
image.
9. Use the on–screen number pad to enter the exact measurements. Tap on
the number pad when finished.
